System Network

TCP/IP+4G +PSTN+Wi-Fi 6

Alarm Zones

64 Wireless+16 Wired + 128 RS485 +48 keyboard expansion zones+ 64 Power Bus+192 CAN BUS zones

Dimensions

(WxHxD) 290x240x87mm

Housing Material

ABS Fire-resistant Box

Wireless Frequency

FSK433MHz/868MHz

Installation Location

Indoor Use For Wall Mounted

Menu Voice Guidance

Customized

DHCP Function

Support

Duress Password

Yes

Entry & Exit Delay

Yes

Number of Users

32 Users + 1 Admin +1 Main

Number of voice phone No.

16

Number of wireless remotes

8

Number of wired keypad

16(Each keypad support extra 3 wired zones)

Number of wireless doorbell

1

Number of wireless Switch

32CH

Partitions And Areas

8

Number of wireless Siren

4 for dual way siren, multiple for single way siren

PGM Outputs

3

Event log

1000

Backup Battery Type

12V DC, 7ah lead acid battery

Max. run time on backup Battery

16 h if connect 1 wired keypad

Max. receiving range (outdoors)

300 m

Max. sending range (Outdoors)

300 m

Power Supply Unit

15V/4A

GSM Dialing Protocols

Ademco Contact ID

IP/GPRS CMS protocol

SIA-TCP, SIA-UDP, Meian CMS

CMS Platform Docking Way
(Central management)

Support 2 CMS Server Address
Main Server+Backup Server
(SIA-TCP,SIA-UDP)

Camera Supported

Support

WEB IE

Support

Mobile App

Android/iOS
