Operating System

Embedded Linux

Video Compression

H.264

GUI

Can connect to Monitor

Video Input

4CH or 8CH, MicroTCA interface, 1.0Vp-p, 75Ω

Video Output

1CH Composite video output, MicroTCA interface, 1.0Vp-p, 75Ω

Preview Function

Single or Multipicture stitching

Recording Definition

Supporting 720P/D1/HD1/CIF, support 4CH 720P Max.

Recording Ways

Auto recording(Default), supporting ignition, manual recording, alarm recording, etc

Audio Input

4CH or 8CH, MicroTCA interface

Audio Output

1CH,MicroTCA interface

Compression

G.726, speed: 40KB/s

Alarm Input

4CH, with linkage alarm function

Alarm Output

1CH Switching Value Output

Positioning

Support, built-in GPS / BD module

Sensor

Support G-SENSOR acceleration sensor

SD Card

1~2pcs SD Card recording, supporting 128GB Max., circulate recording, automatic data coverage

File System

particular vehicle-mounted pre-distribution professional file system

Video Playback

Support multi-channel synchronous playback, pause, fast forward, fast back

Supports 2, 4, 8, 16 times fast forward or back

Power Supply Management

Adaptive wide range power input, with protection functions, such as overload, overvoltage, undervoltage, short circuit, reverse connection, etc.
Support time-power-off support, delay shutdown

Input Voltage

DC:+10V ~ +36V

Output Voltage

+12V@2A,

Power Consumption

normal working<5W

Working Temperature

-20℃to +70℃

Working Humidity

20% to 80%
